Connection
version

The connection is available in various designs
View A
M1 connections
Connection version

It is made as a homogeneous upsetting of the material.

M6 M8
A

It is made as a pressed threaded sleeve welded on the outside of the clamp.

M8 M10 M10/M12 M12/M16
B

It is made as pressed threaded sleeve welded on the inside of the clamp.

M10/M12 M12/M16
C

It is made as a special hexagonal nut pressure welded on the inside of the clamp.

M8 M10
D

It is made as a homogeneous upsetting of the material.

M8/M10
E
Side attachment

Clamps ordering legend

Clamp
Index
Catalogue number
Description
Without pin
BK
_ _ _ _ _ _ _ 0 _

To order such a version, add the index BK at the end of the designation to the order, while in the part number, enter 0 as the penultimate digit of the code.

Complete, with pin, not screwed
KPL
_ _ _ _ _ _ _ 1 _

To order such a version, add the index KPL at the end of the designation to the order, while in the part number, enter 1 as the penultimate digit of the code.

Complete, with pin, screwed
SKR
_ _ _ _ _ _ _ _ 2 _

To order such a version, add the index SKR at the end of the designation to the order, while in the part number, enter 2 as the penultimate digit of the code.

Installation
instructions:

Data
sheet

Fastening and connecting elements

Hex head bolt 105/101-M

  • Corrosion protection: galvanic zinc coating
  • Application: s
Fastening and connecting elements > Hex head bolt 105/101-M

Fastening and connecting elements / Hex head bolt 105/101-M

Product properties

  • Corrosion protection: galvanic zinc coating
  • Application: s

Anti-corrosion coating/material:

Types of coatings/materials:

Anti-corrosion coatings used in the production of our products are the highest quality protection against corrosion of surfaces and installation components that work in environments that require increased resistance to chemical environment, UV and water, ensuring high performance quality parameters.

Galvanized

This is the most common way to protect the surface of metal. Metal components protected with galvanized zinc plating are designed for indoor installation.

Stainless steel

The exceptional corrosion resistance of stainless steel is due to the passivation process of the material. The oxide layer produced, despite its very small thickness, provides resistance to the penetration of corrosive agents and determines the resistance to corrosive environments.

Ultra Cover XP coating

Our latest development is Ultra Cover XP, an ultra-thin anti-corrosion coating that protects products, leaving behind previous galvanizing and hot-dip galvanizing technologies. Ultra Cover XP is a group of advanced lamellar, zinc-nickel and thick-coat passivation coatings, making it very high resistance to external influences.

Main advantages and benefits
  • • superb corrosion resistance
  • • high resistance to temperature and chemical agents
  • •resistance to many mild chemicals and solvents, including gasoline and brake fluid
  • • no occurrence of hydrogen embrittlement in the material
  • •ability to cover complex shapes, recesses and holes
  • • ability to cover complex shapes, recesses and holes
  • • the small thickness of the Ultra Cover XP coating has greater corrosion resistance than the large thicknesses of traditional coatings

The Ultra Cover XP coating consists of several layers. Initially, the product is coated with a base layer that reacts with the surface of the steel, forming, after appropriate processing, a kind of tightly adherent shell. The base is then coated with sealant, which gives the whole the required durability. Ultra Cover XP makes the product more repeatable, durable and weatherproof.

Ultra Cover XP coating is eco!
<p>Ultra Cover XP contains no harmful chromates, is safe for the environment and energy-efficient and low-impact to produce. The coating process offers less energy use and low water consumption than other similar processes.</p>

Hot-dip galvanizing

The thickness of zinc coating is from 45 to 150 microns. Hot-dip galvanization is an exceptional protection against corrosion and im- pact of atmospheric conditions. Hot-dip galvanized products are intended for application, most of all, outside, where they are in contact with atmospheric conditions.

Galvanized
Stainless steel
Ultra Cover XP coating
Hot-dip galvanizing
Thread M Dimensions L [mm] Unit weight [kg] Quantity in package Measurement unit Order designation Catalog number Add all to list Remove all products from the list
M8 20 0.012 50 szt./pcs. 105-M8X20 81402080200 Add to list Remove this product from the list of products
M8 25 0.013 50 szt./pcs. 105-M8X25 81402080250 Add to list Remove this product from the list of products
M8 30 0.015 50 szt./pcs. 105-M8X30 81402080300 Add to list Remove this product from the list of products
M10 35 0.029 50 szt./pcs. 105-M10X35 81402100350 Add to list Remove this product from the list of products
M8 40 0.017 50 szt./pcs. 105-M8X40 81402080400 Add to list Remove this product from the list of products
M8 50 0.021 50 szt./pcs. 105-M8X50 81402080500 Add to list Remove this product from the list of products
M8 60 0.024 50 szt./pcs. 105-M8X60 81402080600 Add to list Remove this product from the list of products
M8 80 0.031 50 szt./pcs. 105-M8X80 81402080800 Add to list Remove this product from the list of products
M8 100 0.035 30 szt./pcs. 105-M8X100 81402081000 Add to list Remove this product from the list of products
M10 20 0.022 50 szt./pcs. 105-M10X20 81402100200 Add to list Remove this product from the list of products
M10 25 0.024 50 szt./pcs. 105-M10X25 81402100250 Add to list Remove this product from the list of products
M10 30 0.0265 50 szt./pcs. 105-M10X30 81402100300 Add to list Remove this product from the list of products
M10 40 0.031 25 szt./pcs. 105-M10X40 81402100400 Add to list Remove this product from the list of products
M10 50 0.036 25 szt./pcs. 105-M10X50 81402100500 Add to list Remove this product from the list of products
M10 60 0.042 25 szt./pcs. 105-M10X60 81402100600 Add to list Remove this product from the list of products
M10 80 0.051 25 szt./pcs. 105-M10X80 81402100800 Add to list Remove this product from the list of products
M10 100 0.063 20 szt./pcs. 105-M10X100 81402101000 Add to list Remove this product from the list of products
M10 120 0.0806 15 szt./pcs. 105-M10X120 81402101200 Add to list Remove this product from the list of products
M8 25 1 10 kg 105-M8X25/KG 81412080250 Add to list Remove this product from the list of products
M8 30 1 10 kg 105-M8X30/KG 81412080300 Add to list Remove this product from the list of products
M10 25 1 10 kg 105-M10X25/KG 81412100250 Add to list Remove this product from the list of products
M10 30 1 10 kg 105-M10X30/KG 81412100300 Add to list Remove this product from the list of products
M10 30 29 1 szt./pcs. 105-M10X30/1000 81422100300 Add to list Remove this product from the list of products
M10 60 21 1 szt./pcs. 105-M10X60/500 81422100600 Add to list Remove this product from the list of products
M12 20 0.032 20 szt./pcs. 105-M12X20 81402120200 Add to list Remove this product from the list of products
M12 25 0.035 25 szt./pcs. 105-M12X25 81402120250 Add to list Remove this product from the list of products
M12 30 0.039 25 szt./pcs. 105-M12X30 81402120300 Add to list Remove this product from the list of products
M12 40 0.046 20 szt./pcs. 105-M12X40(8.8) 81482120400 Add to list Remove this product from the list of products
M12 50 0.053 20 szt./pcs. 105-M12X50 81402120500 Add to list Remove this product from the list of products
M12 60 0.06 20 szt./pcs. 105-M12X60 81402120600 Add to list Remove this product from the list of products
M12 80 0.074 20 szt./pcs. 105-M12X80 81402120800 Add to list Remove this product from the list of products
M12 100 0.088 15 szt./pcs. 105-M12X100 81402121000 Add to list Remove this product from the list of products
M16 50 0.102 10 szt./pcs. 105-M16X50(8.8) 81482160500 Add to list Remove this product from the list of products
M16 65 0.121 10 szt./pcs. 105-M16X65 81402160650 Add to list Remove this product from the list of products
M16 70 0.128 10 szt./pcs. 105-M16X70 81402160700 Add to list Remove this product from the list of products
M16 80 0.141 10 szt./pcs. 105-M16X80 81402160800 Add to list Remove this product from the list of products
M16 100 0.166 10 szt./pcs. 105-M16X100 81402161000 Add to list Remove this product from the list of products
M16 120 0.192 10 szt./pcs. 105-M16X120 94021612001 Add to list Remove this product from the list of products
80 0.238 10 szt./pcs. 105-M20X80 81402200800 Add to list Remove this product from the list of products
M8 100 0.0422 20 szt./pcs. 101-M8X100 81403081000 Add to list Remove this product from the list of products
M8 110 0.046 20 szt./pcs. 101-M8X110 81403081100 Add to list Remove this product from the list of products
M8 120 0.0498 20 szt./pcs. 101-M8X120 81403081200 Add to list Remove this product from the list of products
M10 100 0.07 15 szt./pcs. 101-M10X100 81403101000 Add to list Remove this product from the list of products
M10 120 0.083 15 szt./pcs. 101-M10X120 81403101200 Add to list Remove this product from the list of products
M10 150 0.1 1 szt./pcs. 101-M10X150 81403101500 Add to list Remove this product from the list of products
M8 140 0.0572 20 szt./pcs. 101-M8X140 81403081400 Add to list Remove this product from the list of products
M12 120 0.13 10 szt./pcs. 101-M12X120 81403121200 Add to list Remove this product from the list of products

*Check the availability **Valid while stock lasts. Send inquiries to e-mail: biuro@niczuk.pl
